The S13-M series 200kVA oil immersed distribution transformer represents an advanced, energy-efficient solution for modern 10kV to 0.4kV power networks. Designed to meet strict Tier 2 energy efficiency requirements, it significantly lowers long-term operational costs by reducing no-load losses by approximately 15% to 20% when compared to traditional S11-M models. The unit features a fully sealed (M-type) corrugated tank construction combined with 100% copper windings. This design prevents internal oil degradation, completely isolating the core from ambient air to guarantee a long, maintenance-free service life.
Manufactured with strict quality control, this transformer conforms to IEC 60076 and GB/T 6451 international standards, demonstrating top-tier manufacturing expertise. Below is the core datasheet for bulk procurement evaluation:
Parameter | Specification Details |
Rated Capacity | 200 kVA |
Primary / Secondary Voltage | 10 kV / 0.4 kV (400 V) |
Frequency & Phase | 50/60 Hz, 3-phase |
Connection Group | Dyn11 |
No-load Loss / Load Loss | ≤ 255 W / ≤ 2530 W |
No-load Current / Impedance | ≤ 0.7% / 4% |
Winding Material | 100% copper |
Tank Type & Cooling | Fully sealed (M-type), corrugated / ONAN |
Standards | IEC 60076, GB/T 6451 |
This high-efficiency S13-M transformer is built to deliver stable, continuous power while maximizing energy savings for demanding B2B infrastructural setups. Key applications include:
Industrial plants requiring Tier 2 energy efficiency upgrades.
Commercial buildings and large retail complexes.
Residential areas and urban grid expansions.
As a direct factory manufacturer, we supply fully certified Tier 2 oil immersed transformers to global EPC contractors, electrical wholesalers, and utility developers. These advanced units are available upon request to fit your specific project schedule. Please contact our team with your technical requirements to receive an accurate quotation, MOQ details, and current lead time information.
